DC Power Supply Adjustable 30V 10A, Lab Bench Power Supply with Encoder Knob & U



DC Power Supply Adjustable 30V 10A, Lab Bench Power Supply with Encoder Knob & Usb-A/Type-C Fast Charging Interface, 4 Digit High Precision LED Display, Variable Switching Regulated Power Supply. 29.8 x 19.5 x 12.7 cm; 1.45 kg. Main unit, operating instructions, power cable, output cable. Unlike traditional cumbersome adjustment methods, the TPS series power supply does not require a short circuit to precisely set the voltage and current via the encoder knob and display it in real time on the HD LED screen, and then turn the output on or off via the Output button.

In addition to the short circuit protection, over temperature protection, over voltage protection and over current protection that come with the TPS3010 series power supply itself; this DC power supply is also equipped with the'OCP' function, when you turn on the OCP if the power supply has a short circuit or exceeds the current you set, the power supply will automatically stop output and issue an alarm. This bench power supply is configured with two fast charging ports, USB-A/type-c, and supports a variety of fast charging protocols up to 18W power output, which can power your electronic devices while you work. This DC power supply measures 8.27 (L)5.7 (W)3.15 (H) In, weighing 2.53 lb. TPS series variable power supply can display voltage, current, power and other data at the same time, and automatically calculate output power according to output voltage and current. Automatically switch between constant voltage and constant current modes according to load changes.

Output 0-30V/ 0-10A, voltage display accuracy 0.01V, current display accuracy 0.001A. DC Power Supply1, Power Cord (UK Plug)1, Output Cord1, User Manual (English)1. Each piece of NANKDF series products is tested and aged, and we are committed to improving user experience and service.

We provide after-sales and technical consulting services for this product. TPS series adjustable DC power supplies use encoder adjustment knobs to adjust voltage and current parameters.

The advantage is that the voltage and current values can be set accurately without the need for a short circuit. The current adjustment position can be changed. The value of the current position can be changed. How to adjust the current.

You only need to press the [V/A] button to switch the voltage or current. Separate output buttons to switch the output of the power supply on or off without switching it off. In the event of an OCP (Short Circuit Alarm), pressing the OUTPUT button disarms the alarm and closes the output state. When the output is switched on.

The display will show the OUT green mark. When the output is switched off. The OUT logo disappears and the output is switched off. The TPS series DC power supply has added the protection function for external products (ocp), when the OCP (overcurrent protection) mode is turned on, the power supply will automatically cut off the output and send out an alarm if the output exceeds the limiting current value or if a short circuit occurs externally. Press the OCP button to turn on OCP mode, the screen will display OCP when it is turned on.

Press again to switch off OCP. With the addition of USB-A and Type-c fast charging ports, the TPS3010 series of variable benchtop power supplies can power your electronic devices and save you bench space. It is a powerful helper for electronics enthusiasts. The USB-A/Type-c has built-in fast charging protocols with a maximum charging power of up to 18 W.

It can provide fast charging for electronic devices with fast charging function, and automatically adjusts the output voltage and current according to the fast charging protocols of the electronic devices it is charging. If the device does not have fast charging function, it will be powered by standard 5V.

30V/10A Adjustable DC Power Supply1. AC power cord (UK plug)1. Key beeps for variable DC power supplies.

How do I turn off the key beep? (Please set it according to the following steps). Press and hold the output button for about 3-5 seconds to enter setup mode.

After entering Setup, press the Voltage Adjustment Knob four times to enter Mode 4. In Mode 4, rotate the Voltage Adjustment Knob to turn off the key tone when the number in the Power Indication Window reaches zero. After turning off the beep tone, continue to press the Voltage Adjustment Knob until exiting Setup Mode (after exiting, the settings will be automatically saved). Please note: If you need to save the settings, you need to keep pressing the encoder knob until you exit the settings page. Screen brightness can also be set according to the above steps (brightness set to mode 3). We offer the best prices around on high quality products. Our E-store includes media such as books, movies, music and games while offering electronics, toys, sporting apparel, clothing, tools, general home, garden items and more. We are always working hard to ensure your package arrives as soon as possible. We try our very best to make sure every customer is completely satisfied. If there's a problem, message us! We're happy to help.
